GA800 drives and reduced size configured packages now available up to 1000 HP
Yaskawa America, Inc. has announced the following expansions to the GA800 AC drive product line:
- GA800 frame 12 standard drives – 480V, 700 to 1000 HP
- GA800 480V, 700 to 1000 HP Configured Packages – Types 1, 12, and 3R
- GA800 480V, 400 to 600 HP Configured Size Reduction
GA800 Frame 12 Standard Drives – 480V, 700 to 1000HP
GA800 frame 12 is available in the following ratings, making the 480V power range equivalent to the A1000.
| Catalog Code | Normal Duty Rating | Heavy Duty Rating |
| GA80U4810AAM | 700 HP (810 A) | 600 HP (720 A) |
| GA80U4930AAM | 800 HP (930 A) | 700 HP (810 A) |
| GA80U4H11AAM | 900 HP (1090 A) | 800 HP (930 A) |
| GA80U4H12AAM | 1000 HP (1200 A) | 900 HP (1090 A) |
Notable features of GA800 frame 12
- 39% smaller in width than previous generation A1000 drive
- 34% lighter than A1000 drive
- Field configurable for 6-pulse or 12-pulse input (no special model required)
- Accepts Type 12 external heatsink kit (no special flange model required)
GA800 480V, 700 to 1000 HP Configured Packages – Types 1, 12, and 3R
Like all existing GA800 configured packages, these new high-power packages have various configuration options and offer the same power ratings as the frame 12 standard drives.
Notable features of GA800 Configured 700 to 1000 HP
| Type 1 and Type 12 | Type 3R |
GA800 480V, 400 to 600 HP Configured Size Reduction
To complement the new frame 12 ratings, Yaskawa has repackaged the 400 to 600 HP Normal Duty (350 to 500 HP Heavy Duty) configured offering as follows. These ratings were previously in a 2-door floor mount and are now reduced to a single-door floor mount.
| Previous Type 1 and Type 12 | Repackaged Type 1 and 12 |
For more information about Yaskawa America, visit yaskawa.com.
