MakerBot’s New Extruder has been Torn Down

3d printing, extruder, fabbaloo, tear down

The folks at intentional3D have managed to acquire a new MakerBot fifth generation Replicator and performed a tear down on the fancy new “Smart” extruder.

They wanted to find out how the component is able to prevent filament jams and generally see how difficult it would be to repair it if required. Among the discoveries:

  • A cylindrical tube was originally intended to be the filament input route, but MakerBot apparently decided not to use it at the last minute due, as the “sharp turn” could snap the filament.
  • The extruder is truly an aggregation of all the discoveries MakerBot and others have made in the past few years.
  • A hidden magnet performs an unknown mechanical function, perhaps related to stabilizing the extruder’s movements.
  • A tiny circuit board at the top includes a switch that is used to detect whether filament is present.

Read More at Fabbaloo
