The certifications support high-performance photonic component design for next-gen PICs.
Ansys and GlobalFoundries collaborated to certify four Ansys photonic solvers, empowering engineers to simulate passive and active photonic components with high-fidelity in the GF Fotonix platform. Together, Ansys and GlobalFoundries enable access to reliable, multiphysics simulation solutions that address design challenges for a range of high-capacity chips — including those used in generative AI, autonomous vehicles, hyperscale data center communications, and IoT.
GF Fotonix is a feature-rich and highly flexible silicon photonics platform and is the only commercially available foundry platform for the monolithic integration of photonic and electronic components with the option of a photonics-only flow. The photonic components include active devices such as Mach Zehnder and Micro-ring modulators and Germanium photodiodes, and passive components such as splitters, multi-mode interferometers, phase shifters/rotators, tapers, bends, and filters for wave division multiplexing. The platform allows designers to develop custom solutions for their system applications for high-speed optical communications to address their high-bandwidth, low-latency data transmission, and low power consumption requirements.
GF Fotonix has certified four Ansys Lumerical solutions for the GF Fotonix platform — FDTD, MODE, CHARGE, and HEAT. The certifications span a wide range of capabilities, from passive to active photonic component design, including modeling the effects of electrical and thermal stimulus on optical behavior. Ansys and GlobalFoundries have benchmarked the solvers against real measurement data, ensuring high-fidelity simulations for mutual customers.
Designers interested in utilizing Ansys tools with GF Fotonix can contact the GF sales team to download RFL-000206-silicon photonics reference flow based on Ansys-CML compiler 4×4 optical switch and RFL-000168 45SPCLO Ansys Lumerical simulation flow.
For more information, visit ansys.com.
