Desktop Metal announced the launch of 4140 chromoly steel for the Studio System, an office-friendly metal 3D printing system for prototyping and low volume production. One of the most versatile chromoly steels, 4140 is characterized by its toughness, high tensile strength, and abrasion and impact resistance, making it a key all-purpose steel for industrial applications.
“As global demand for the Studio System grows, Desktop Metal is broadening its materials portfolio to include 4140 chromoly steel, enabling designers and engineers to print a variety of critical industrial applications, such as couplings, forks, pinions, pump shafts, sprockets, torsion bars, worm gears, connecting rods, and fasteners,” said Ric Fulop, CEO and co-founder of Desktop Metal. “Now, teams around the world will be able to leverage the Studio System to iterate quickly on 4140 prototypes and ultimately produce end-use, customer-ready parts faster and more cost-effectively.”
Early applications of 4140 parts printed with the Studio System illustrate the benefits across a variety of industries, including automotive, oil and gas, pumps and hydraulics, agriculture and defense, among others:
Automotive: Connecting Rod
During combustion, connecting rods experience significant loads and must endure high temperatures, so functional testing must be conducted using metal parts. 4140 is a key material choice for this application as it can withstand the high temperatures and mechanical stresses experienced by connecting rods. With the Studio System, users have the ability to create functional prototypes in days, and then rapidly iterate on those designs. This ensures engineers can develop efficient components and validate how they perform before committing to the manufacture of potentially millions of parts via casting or forging.
Agriculture: Mechanical Coupling
When off-the-shelf parts don’t suffice, custom mechanical couplings must be fabricated for the specific application – a process that can be both time-consuming and expensive. The complex geometry and fine features of this particular coupling, used to attach a motor in a hopper metering system, make it a difficult and expensive part to machine. With the Studio System, the design team can produce a prototype of this part in days, then test its functionality in the machinery where it will be used. Printing this part allows engineers to create working models of machinery faster and with less expense. By printing in 4140, the material’s high torsional strength also enables it to stand up to the stresses couplings must withstand on a day-to-day basis.
“It’s well-known in additive manufacturing that the selection of metal materials is limited to a few options for high value-added parts,” said Dominique Ghiglione, R&D Manager – Materials & Process at CETIM, the Technical Centre for Mechanical Industry. “The fact that Desktop Metal offers 4140 is excellent news for the mechanical industry. This material is indeed the ‘Swiss army knife’ because of its good performance-to-cost ratio and its mechanical characteristics. This material is found in many automotive components, special machines, construction machinery, agricultural machinery, and so on. CETIM knows this material very well for having used it for a number of mechanical applications. Having this steel to use with our Studio System will allow us to effectively continue the spread of metal additive manufacturing within the mechanical industry.”
Industry: Sheet Metal Tooling
Press brake tools are used to create bends in sheet metal with a wide range of applications – from the production of heavy-duty metal parts, to electronics enclosures. This tool in particular is used to create a custom bend angle in aluminum. The long lead times and increased costs that accompany custom tooling make it impractical for smaller or specialty jobs. Now 3D printing with the Studio System allows shops to quickly create custom tools like this one and take on specialty jobs, while still keeping cost per-part low. 4140 is an ideal material choice for the production of this press brake tool due to its toughness and resistance to impact.
