Adjusting Sketch Dimensions in SOLIDWORKS 2016 with Instant 2D

Users need only click a dimension once to update its values, unlike previous versions.

The Instant 3D feature in SOLIDWORKS allows users to drag geometry dynamically in the graphics area to resize a sketches dimensions.

With the SOLIDWORKS 2016 update, the new Instant 2D update allows users to do the same thing in a sketching environment. In the tutorial video below, we’re going to edit a sketch to illustrate this process.

Users must first toggle on the Instant 2D feature in the feature manager. Selecting a dimension will create blue control handles around the sketch.

Blue handles appear around the sketch after Instant 2D has been toggled on and a dimension has been selected.

Users only have to drag a handle to adjust the dimension and its related sketch geometry dynamically. A ruler feature appears to help track changes being made.

Dragging the control handle adjusts the dimension and its related sketch geometry. A ruler feature helps keep track of adjustments.

Instant 2D also eliminates the need to rebuild a sketch after dimension changes have been made.

In prior versions, users had to double-click the dimension, enter a new value and rebuild to see their changes. When Instant 2D feature is active, users only have to click a dimension once to update its value.
